Vehicle Grain Suction Machine Pneumatic and motor-driven bulk grain conveyors for truck loading and grain lifting, this article will explain Vehicle Grain Suction Machine in detail.
Vehicle Grain Suction Machine can be installed on the carriage, equipped with grain suction, grain cleaning, and conveying devices, which can be bent, moved, and easy to carry. Loading and unloading trucks, clearing the bottom of the warehouse, etc., the Vehicle Grain Suction Machine is small and flexible, and the loading and unloading is fast and convenient.
Vehicle Grain Suction Machine is generally composed of feed inlet, Oxford tube, shaftless screw, discharge outlet, machine base, motor (gasoline and diesel engine, worm gear reducer) and other parts. When the material enters the Oxford tube evenly and moderately from the inlet, the motor (gasoline and diesel engine) drives the spiral piece to rotate through the pulley, and then the material is transported to the outlet at one end of the chassis, and then falls into the carriage, warehouse, nylon bag and other material receiving place. The efficiency can reach 25 tons per hour, and the lifting height is 8 meters. When the horizontal distance is 6-30 meters, the bending radius of the hose should not be less than one meter.
1. One machine is multi-purpose, can absorb grain, and can also be used for non-corrosive granular materials such as granular fertilizer, feed, chemical products, etc., and can harvest 6-8 tons of grain in one hour.
2. The vertical height can reach 4 meters, and the horizontal transportation distance is 5-30 meters. Fully meet the needs of general applications.
3. The damage rate is low, the damage rate is less than 0.2%, reducing the damage to grain and food.
4. The whole machine is light in weight, occupies a small area, and is easy to move and install.
3kw two-phase/3KW three-phase copper wire motors can be used below 7m of the machine, and 4kw three-phase electric copper wire motors can be used between 8m-12m. Generally, the vertical height of 220V is 3 meters, and the vertical height of 380V is 4 meters (the data is generally in food shall prevail)
Vehicle Grain Suction Machine is used for loading and unloading, unloading, overturning, stacking, bulk and bulk transportation in farms, wharves, stations, large grain depots, etc. It is used for mechanized operations of bulk unloading. According to the requirements of grain transportation, it can be A single unit, a combination of multiple units, or a conveying system with other equipment can meet different operating requirements.
