Screw conveyor is a commonly used material conveying equipment. It consists of a conveying pipe, a spiral blade, an inlet, an outlet, etc. According to different working conditions and conveying requirements, the screw conveyor can be divided into various models, the following is the screw conveyor parameter table.
| Model | Speed (r/min) | Conveying capacity (m³/h) | Power (kw) | Angle (degrees) | Diameter (mm) | Length (m) |
LS100 | 75-180 | 2.2-6.5 | 1.1-2.2 | 0-60 | 100 | 3-30 |
LS200 | 75-180 | 5.5-16.5 | 3-7.5 | 0-60 | 200 | 3-40 |
LS315 | 60-165 | 12-37 | 5.5-15 | 0-60 | 315 | 3-50 |
LS400 | 60-165 | 22-65 | 7.5-22 | 0-60 | 400 | 3-50 |
LS500 | 40-160 | 35-100 | 11-30 | 0-60 | 500 | 3-50 |
LS630 | 40-120 | 65-140 | 22-45 | 0-60 | 630 | 3-50 |
LS800 | 20-110 | 100-280 | 30-75 | 0-60 | 800 | 3-50 |
Through the above table, we can see that there are many types of screw conveyors, and different types of screw conveyors have different characteristics, uses and scope of application. Below we will introduce the characteristics and uses of each model one by one.
LS100 screw conveyor is a small conveying equipment, suitable for conveying non-viscosity or low-viscosity materials. Due to its small size, light weight and low power requirements, it is often used for feeding equipment such as crushing, screening, and drying, and can also be used for transportation in industries such as building materials, chemicals, and electric power.
LS200 screw conveyor is larger than the LS100 model and has a greater conveying capacity, and is suitable for conveying medium-viscosity materials such as plaster, cement and other chemicals. Usually used in cement plants, building materials plants, chemical plants and powder processing enterprises.
LS315 screw conveyor is a medium-sized conveying equipment, suitable for conveying powdery, granular and blocky materials. Commonly used in the transportation of flour, feed, food and other industries, and also commonly used in cement, chemical and environmental protection equipment and other industries.
The LS400 screw conveyor has the characteristics of large conveying capacity, long conveying distance and adjustable angle, and is suitable for conveying high-viscosity and high-wear materials. Commonly used in sugar, feed, food, building materials, chemical and other industries.
LS500 screw conveyor has the characteristics of large conveying capacity, long conveying distance and wide application range. It is suitable for conveying various powdery, granular and block materials. Mainly used in cement, chemical, metallurgical and other industries.
6. LS630 screw conveyor
LS630 screw conveyor has the characteristics of large conveying capacity, long conveying distance, adjustable angle, etc. It is suitable for conveying powdery, granular and block materials. It is especially suitable for conveying furnace materials in cement, chemical, metallurgical and other industries.
LS800 screw conveyor is a large-scale conveying equipment, which has the characteristics of strong conveying capacity, long conveying distance and wide application. It is mainly used for material transportation in large-scale projects such as cement, chemical industry, metallurgy, and electric power.
To sum up, there are many types of screw conveyors, and each model has different characteristics, uses and scope of application. According to different working conditions and conveying requirements, it is very important to choose a suitable screw conveyor.
