Tubular Screw Conveyor is a common material conveying equipment in industrial production. It is mainly used for conveying powder, granular and block materials in cement, food, chemical, metallurgy, mining and other industries. According to different material characteristics and process requirements, Tubular Screw Conveyor can be divided into different models. The following briefly introduces the characteristics and parameter tables of each model.
LS-type Tubular Screw Conveyor is a medium-low speed conveying equipment with a material conveying capacity of up to 80t/h. It is mainly suitable for conveying various dry powder materials and small lump materials, such as cement, coal ash, lime, powder, granules, etc. , Commonly used in industries such as cement plants, chemical fertilizer plants, grain storage and transportation, and construction sites.
The parameter list of LS type Tubular Screw Conveyor is as follows:
| Model | Material Conveying Capacity (t/h) | Rotational Speed (r/min) | Standard Length (m) | Spiral Diameter (mm) |
| LS100 | 10-30 | 80 | 0.8-8 | 100 |
| LS200 | 15-50 | 80 | 0.8-8 | 200 |
| LS250 | 25-80 | 80 | 0.8-8 | 250 |
| LS300 | 40-130 | 80 | 0.8-8 | 300 |
GX-type Tubular Screw Conveyor is a medium-low speed conveying equipment with a material conveying capacity of up to 240t/h. It is suitable for new tubular conveying equipment used in metallurgy, coal, grain, chemical and other industries. It has large conveying capacity and long conveying distance. , The conveying height is high, and it has outstanding advantages in terms of large conveying capacity, energy saving and consumption reduction. GX type screw conveyor can be divided into two types: single head and double head. The conveying capacity of single head is generally not more than 100t/h, and the conveying capacity of double head can reach more than 2000t/h.
GX type Tubular Screw Conveyor parameter table is as follows:
| Model | Material Conveying Capacity (t/h) | Rotational Speed (r/min) | Standard Length (m) | Spiral Diameter (mm) |
| GX100 | 20-60 | 75 | 3-30 | 100 |
| GX200 | 30-120 | 75 | 3-30 | 200 |
| GX250 | 40-180 | 75 | 3-30 | 250 |
| GX300 | 60-240 | 75 | 3-30 | 300 |
GL type Tubular Screw Conveyor is a medium-low speed conveying equipment with a material conveying capacity of up to 130t/h, suitable for conveying cement, lime, mineral powder and other materials. This type of conveyor is simple in structure and easy to operate and maintain.
The parameter table of GL type Tubular Screw Conveyor is as follows:
| Model | Material Conveying Capacity (t/h) | Rotational Speed (r/min) | Standard Length (m) | Spiral Diameter (mm) |
| GL100 | 15-45 | 75 | 3-30 | 100 |
| GL200 | 20-70 | 75 | 3-30 | 200 |
| GL250 | 30-100 | 75 | 3-30 | 250 |
| GL300 | 40-130 | 75 | 3-30 | 300 |
GLS type Tubular Screw Conveyor is a medium and low speed conveying equipment with a material conveying capacity of up to 250t/h, suitable for conveying powdery, granular and small lump materials. This type of conveyor is small in size and easy to install and maintain.
GLS type Tubular Screw Conveyor parameter table is as follows:
| Model | Material Conveying Capacity (t/h) | Rotational Speed (r/min) | Standard Length (m) | Corrugation Distance (mm) |
| GLS100 | 20-70 | 67 | 4-16 | 220 |
| GLS200 | 30-100 | 67 | 4-16 | 220 |
| GLS250 | 40-150 | 67 | 4-16 | 220 |
| GLS300 | 60-200 | 67 | 4-16 | 220 |
GLD Tubular Screw Conveyor is a high-speed conveying equipment with a material conveying capacity of up to 800t/h. This type of conveyor can be used to transport materials such as cement, sintered ore, ash and slag, and is suitable for medium and long-distance mass transportation.
GLD type Tubular Screw Conveyor parameter table is as follows:
| Model | Material Conveying Capacity (t/h) | Rotational Speed (r/min) | Standard Length (m) | Spiral Diameter (mm) |
| GLD100 | 50-150 | 160 | 6-20 | 100 |
| GLD200 | 100-300 | 160 | 6-20 | 200 |
| GLD250 | 150-500 | 180 | 6-20 | 250 |
| GLD300 | 300-800 | 200 | 6-20 | 300 |
In short, different types of Tubular Screw Conveyor are suitable for different material conveying requirements, and the selection should be made according to the actual situation.
