There are many models of Tubular Screw Conveyor. Here are several commonly used Tubular Screw Conveyors as examples to introduce:
LS Tubular Screw Conveyor is suitable for horizontal or inclined conveying of powdery, granular and small block materials, such as coal, ash, slag, cement, grain, etc. The temperature of the material is less than 200 ℃, and it is not suitable for conveying perishable, viscous, easily Clumped material.
The diameter of LS Tubular Screw Conveyor ranges from 100mm to 1250mm, and there are twelve specifications in total. It is divided into two types: single drive and double drive. The length of single drive screw conveyor can reach 40m (extra large 30m). Structure, the length can reach 80m (extra-large 60m), the length of the screw machine is 0.5m, which can be selected according to the needs, and the conveying capacity per hour is 1.2-458m³/h.
GX type Tubular Screw Conveyor is designed and manufactured according to JB/T679-95 "Screw Conveyor" standard. It is a replacement product of LS type screw conveyor. It is suitable for conveying small particle size and powdery materials, not suitable for conveying perishable and viscous materials. And materials that are easy to agglomerate can be divided into two types: horizontal screw conveyor and vertical screw conveyor.
GX Tubular Screw Conveyor helical diameter: 150mm, 200mm, 250mm, 300mm, 400mm, 500mm, 600mm, different types of GX Tubular Screw Conveyor conveying capacity is not the same, under normal circumstances, its conveying capacity is between 5.6-93m³/h between.
GL Tubular Screw Conveyor is suitable for horizontal conveying, inclined conveying, vertical conveying and other forms of granular or powdery materials, such as: flour, grain, cement, fertilizer, ash, sand, gravel, coal powder, small lump coal, etc.
The specifications of GLTubular Screw Conveyor range from 120 to 600, and the materials are carbon steel and stainless steel, and the conveying distance is from 2 meters to 70 meters.
The above are several common models of Tubular Screw Conveyor. Dahan Tubular Screw Conveyor has a complete range of models, which can be customized for free according to user needs. Users are welcome to buy at any time.
